Chapter 8
8.3 Main GUI
Additional information for inertial sensors In the Data display additional information
is provided for inertial sensors:
• sensor ID
• battery level
• temperature in
◦
C
i
The temperature values between single inertial sensors may vary. The
operating temperature is reached as soon as there are no more tem-
perature changes inside the sensors indicated by a green status bar. It
is not dependent on the absolute temperature value.
3DOF measurement results On the right hand side, the Data display shows the 3DOF
measurement results. All recognized markers that have not been assigned to a calibrated
6DOF body (i.e. uncalibrated targets) and single markers are shown here.
Note: The calculation of 3DOF markers has to be activated in Settings → Tracking by
ticking the checkbox. By default, the calculation is deactivated.
8.3.3.3 Fingertracking
The Fingertracking display shows the measurement results of the hands - i.e. of each
finger (thumb, index, middle, ...) - that are available in the measurement volume. A simple
colour code indicates the status of the Fingertracking:
green ... Fingertracking device is being tracked; tracking data is displayed
yellow ... Hand-target is being tracked (i.e. fingers are calibrated, but out-
side cameras FoV); last known tracking data is displayed
red ... Fingertracking device is not being tracked (e.g. only back of the
hand is calibrated); last known tracking data is displayed
white ... Fingertracking device is not calibrated; columns are left blank
The coordinate system of the measurement data may be switched by using the radio
buttons hand and room. You can distinguish between the hands either by the hand ID or
by the name of the hand geometry.
8.3.3.4 Flystick
The Flystick display shows the measurement results of the position and orientation of the
Flystick. Additionally, the operation of the Flystick buttons and of the joystick are shown.
A simple colour code indicates the status of the Flystick:
green ... Flystick is being tracked; tracking data is displayed
red ... Flystick is not being tracked (e.g. Flystick has not been assigned
to ART radio transceiver); instead of tracking data dashes are
displayed
blue ... button is being pressed
white ... Flystick is not calibrated; columns are left blank
139
