Appendix A
A.1 Cameras
A.1.4 ARTTRACK cameras (discontinued)
ARTTRACK2.2 ARTTRACK3.2 ARTTRACK2 ARTTRACK3
from S/N #1800 from S/N #400
IR flash 880nm 850nm 880nm 850nm
Power supply
Nominal voltage 12V 48V 12V 48V
Maximal current 2A 1.4A 2A 1.4A
Maximal power 25W 35W 25W 35W
Ext. power supply 12.2V / 3A / 40W 48V / 0.8A / 40W 12.2V / 3A / 40W 48V / 0.8A / 40W
12.5V / 3A / 40W 48.2V / 0.8A / 40W 12.5V / 3A / 40W 48.2V / 0.8A / 40W
Protection category
Ext. power supply I I I I
Camera III III III III
Interface connectors
data RJ45 RJ45 RJ45 RJ45
synchronization BNC BNC BNC BNC
power external external external external
Operating conditions
Temperature 0 .. 38
◦
C 0 .. 38
◦
C 0 .. 38
◦
C 0 .. 38
◦
C
Relative humidity 5 .. 50% 5 .. 50% 5 .. 50% 5 .. 50%
non-condensing non-condensing non-condensing non-condensing
Cooling system active (fan)
→ noise level of
the fan: 16.5dB(A)
passive active (fan)
→ noise level of
the fan: 16.5dB(A)
passive
Dimensions
Length 140mm 140mm 140mm 140mm
Width 78mm 106mm 78mm 106mm
Height 109mm 120mm 109mm 120mm
Weight 0.96kg 1.45kg 0.96kg 1.45kg
‘ Performance
Frame rate max. 60fps max. 60fps max. 60fps max. 60fps
(adjustable) (adjustable) (adjustable) (adjustable)
Max. working distance with 12mm passive markers (F .. focal length in mm).
Greater distances achievable with bigger passive markers (e.g. 30mm) or active markers.
@ F = 2.6mm 4.5m 4.5m 4.5m 4.5m
@ F = 3.5mm 4.5m 4.5m 4.5m 4.5m
@ F = 4.5mm 4.5m 6m 4.5m 6m
@ F = 6.0mm 4.5m 7m 4.5m 7m
Maximum number of 6DOF targets (simultaneously)
@ 60fps 50 50 50 50
Field of view (FoV, horizontal × vertical)
@ F = 2.6mm 88
◦
× 58
◦
88
◦
× 58
◦
- -
@ F = 3.5mm 67
◦
× 45
◦
67
◦
× 45
◦
72.8
◦
× 58.2
◦
72.8
◦
× 58.2
◦
