Appendix A
A.4 FINGERTRACKING2 Tactile
A.4 FINGERTRACKING2 Tactile
Function
Synchronization via modulated IR flash
Battery
1
2 Micro-AAA batteries, each 1.2 - 1.5 V, typ. 900 mAh
Continuous operation with tactile feedback
2
typ. 6 hours
Continuous operation no tactile feedback
3
typ. 7 hours
Battery charger
Input AC 100-240V, 50/60Hz, 0.35A or DC 12V
Charging time
1
approx. 2 hours
Weight (without batteries) approx. 0.2 kg
Operating conditions
Operating temperature 10 .. 40
◦
C
Relative humidity 5 .. 50%, non-condensing
Dimensions
Thimble set available in 4 different sizes (extra-small, small, medium, large)
Weight 60g
Performance
Frame rate (handtarget) up to 300Hz
Frame rate (thimbles, 3-finger version) 100Hz
Tracking range 4m (depending on focal length of the cameras)
1
valid for new batteries
2
300 Hz tracking frequency, LED brightness setting high, 1 vibration per second
3
300 Hz tracking frequency, LED brightness setting high
A.5 ART Controller
Dimensions
Rackmount (19")
Size 480mm × 345mm × 135mm
Weight 9.75 kg
Power Supply
Voltage 110 - 240 V
max. power consumption 360 W
Connectors
Synchronization in 1, BNC: Video Signal (75Ω), TTL, LVTTL
Camera ports 8, Ethernet 1 GBit/s, PoE+
Data out 1, Ethernet 1 GBit/s
USB 6
Operating conditions
243
