Appendix A
A.1 Cameras
Relative humidity 5 .. 50% (non-condensing)
Cooling system passive
Dimensions
Length 92mm
Width 100mm
Height 100mm
Weight 0.96 kg
A.1.2 ARTTRACK5/C
IR Source
invisible IR 850nm
flash intensity adjustable in 100 steps
Performance
Sensor resolution 1.3 MPixels
Frame rate up to 300 Hz
Field of view (FoV)
Lens Camera mode
Resolution Medium Speed
1.3 MPix 0.8 MPix 0.5 MPix
150 Hz 240 Hz 300 Hz
F = 4.0mm FoV (horizontal x vertical) 89
◦
× 71
◦
71
◦
× 52
◦
56
◦
× 42
◦
Max. tracking range
(12mm markers)
4.5m 4.0m 3.5m
Connectivity & Power Supply
single cable solution via Gigabit Ethernet, RJ45, PoE+ (IEEE 802.3at Standard)
max. cable length 100m
cable length to remote
camera head
60cm
Voltage 44 - 57 V (defined by the Standard)
max. power consumption 12 W
Protection category III
Interface connectors RJ45 (hosts data, synchronization and power)
Operating conditions
Temperature 0 .. 38
◦
C
Relative humidity 5 .. 50% (non-condensing)
Cooling system passive
Dimensions remote camera head
Diameter 37mm
Length 73mm
Weight 160g
237
