Continuation for Both Variants
Pulling bearing inner race off wheel hub
– Install separating tool behind bearing inner ring.
1 - Puller - Kukko Separating Tool - Diameter 25-155mm -
15/3- , the beveled parts of the blades face the bearing inner
ring.
2 - Bell - T10205/2-
3 - Hydraulic Press - VAS6178-
4 - M20 Nut - T10205/8-2-
5 - Thrust Piece - T10205/3-
6 - M20 Nut - T10205/8-2-
7 - Threaded Rod M20 - T10205/8-1-
WARNING
When pulling off, hold tool so that bearing inner ring points
downward (danger of accident if bearing inner ring jumps off at
end of pulling process).
– Pull off wheel hub from bearing inner ring.
Wheel Bearing, Pressing In
Caution
• Avoid contaminating with dirt and damaging the seal when
setting down/storing.
– Make sure that rubberized sensor ring for ABS -arrow- points
toward rear final drive.
If no rubberized ring is visible, check for example with a paper
clip, which of the two sides is magnetic. This side must face rear
final drive when installed.
Note
The tapered holes and the contact surfaces on the outer circum‐
ference of the wheel bearing must be free of oil, grease and
preserving agent.
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
96 Rep. Gr.40 - Front Suspension
