– Remove front noise insulation -1- and -2-.
– Remove noise insulation bracket -arrows-.
– Remove head shield -A- from steering gear.
– Remove screws -1- and -2- and remove left primary catalytic
converter strap.
Note
Place a cloth under separation point to absorb escaping hydraulic
oil.
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
374 Rep. Gr.48 - Steering
