Pin assignment D-sub on front side X3 (male) of incremental encoder emulation:
Further information see manual add-on module EtherNet/IP
®
, 5.16010.
Pin assignment Pin No. Channel Assignment
D-sub male connector
25-pin
1 1 Ground incremental encoder emulation
2 1 External power supply +5 V
3 1 Incremental encoder emulation track 0
4 1 Incremental encoder emulation track -0
5 1 Incremental encoder emulation track B
15 1 Incremental encoder emulation track -A
16 1 Incremental encoder emulation track A
17 1 Incremental encoder emulation track -B
9 2 Ground incremental encoder emulation
10 2 External power supply +5 V IEE
11 2 Incremental encoder emulation track 0
12 2 Incremental encoder emulation track -0
13 2 Incremental encoder emulation track B
23 2 Incremental encoder emulation track -A
24 2 Incremental encoder emulation track A
25 2 Incremental encoder emulation track -B
