Description of the Software Modules and Parameters
Parameter manual b maXX BM5800
Document No.: 5.16029.03
205
of 814
3
116.3 DI1 Axis index
This parameter specifies which axis (0: axis 1, 1: axis 2, 255: both axes) the parameter
being changed should act on.
The parameter acts only on input linkages and not on the other functions (Quick stop, etc.,
see mode digital input 1,
Z116.2–).
116.4 Target number digital input 1
Number of the parameter to be changed by digital input 1.
116.5 Bit selection digital input 1
This parameter specifies which bits of the target parameter will be modified with the bit
pattern Low/High.
If the data of the target parameter is of type Float, no bit selection can be made; all the
bits written to the target parameter will always be of the bit pattern Low or High.
Bit # Meaning
5 … 0 Function of the input:
Value: Function
0: No special function
1: Quick stop
2: Controller enable
3: Error reset
4: Negative hardware limit switch 
5: Positive hardware-limit switch 
6: Zero point reference switch
7: Reset time stamp for ring buffer recording
8 Feedback of motor holding brake
9…63 Reserved
6 axis reference for the special function:
0: axis 1
1: axis 2
7 0: Apply special function to axis according to Bit 6
1: Apply special function to both axes. Bit 6 will be ignored.
13 ... 8 Reserved
14 0: Input is edge triggered
1: Input is level triggered
15 0: Input is not inverted
1: Input is inverted
