Set Value Generators
Parameter manual b maXX BM5800
Document No.: 5.16029.03 Baumüller Nürnberg GmbH
362
of 814
3.6
3.6.1.4 Description of the Parameters
110.1 Status
Status of the ramp function generator
110.5 Input 16 bit INT -16384 16384 0 % 4000
hex
:
100%
X X X
110.6 Ramp-up time UDINT 0 650000 0 ms 1:1 X X X
110.7 Ramp-down time UDINT 0 650000 0 ms 1:1 X X X
110.8 Quick stop time UDINT 0 650000 0 ms 1:1 X X X
110.9 S-curve ramp-up time UDINT 0 650000 0 ms 1:1 X X X
110.10 S-curve ramp-down time UDINT 0 650000 0 ms 1:1 X X X
110.11 Smoothing UINT 0 32767 0 ms 1:1 X X
110.12 Set value zone UDINT 0x0 0x80000000 0 % 400000
00
hex
:
100%
X X
110.13 Maximum drive speed FLOAT 1 1.000000e+06 3000 U/min 1:1 X
110.14 Output acceleration FLOAT -5000000000 5000000000 0 Inc/ms
²
1:1 X
110.15 Input max. amount UDINT 0 1073741824 1073741824 % 400000
00
hex
:
100%
X X X
110.16 Input min. amount UDINT 0 1073741824 0 % 400000
00
hex
:
100%
X X X
110.17 Input 32 bit additive DINT -1073741823 1073741823 0 % 400000
00
hex
:
100%
X X X
110.20 Controlled stop time UDINT 0 65000 1000 ms 1:1 X X X
110.21 SS1 stop time UDINT 0 650000 0 ms 1:1 X X X
110.22 Active cycle time ramp
generator
FLOAT 0 8.0 1 ms 1:1 X
Bit Meaning
0 1: Ramp generator is switched on
3 … 1 Reserved
4 1: FG output is set internally to 0 (FG INHIBIT)
5 1: FG has been halted on the ramp (FG STOP)
6 1: FG input is set internally to set value 0 (FG ZERO)
7 1: Quick Stop ramp is active (FG QSTOP)
8 1: Ramp-up is active
9 1: Ramp-down is active
