Set Value Generators
Parameter manual b maXX BM5800
Document No.: 5.16029.03 Baumüller Nürnberg GmbH
374
of 814
3.6
3.6.2.2 Description of the Parameters
132.1 Mode
Control of the set value generator
Number Name Type Min Max Default Value Unit Factor
Read only
Storage
DS Support
Cyclic Write
Axis-independent
132.1 Mode DWORD 0 0xFFFFFFFF 0 1:1 X
132.2 Status DWORD 0 0xFFFFFFFF 0 1:1 X
132.3 Output FLOAT -5000000000 5000000000 0 1:1 X
132.4 Target number output UDINT 0 0xFFFFFFFF 0 1:1 X
132.10 Set value 1 FLOAT -5000000000 5000000000 0 1:1 X
132.11 Duration zone 1 UDINT 1 4294967295 1000 ms 1:1 X
132.12 Set value 2 FLOAT -5000000000 5000000000 0 1:1 X
132.13 Duration zone 2 UDINT 1 4294967295 1000 ms 1:1 X
132.14 Set value 3 FLOAT -5000000000 5000000000 0 1:1 X
132.15 Duration zone 3 UDINT 1 4294967295 1000 ms 1:1 X
132.16 Set value 4 FLOAT -5000000000 5000000000 0 1:1 X
132.17 Duration zone 4 UDINT 1 4294967295 1000 ms 1:1 X
Bit # Meaning
0 0: Deactivate set value generation
1: Activate set value generation
1 Processing only when set value generation activated (bit 0 = 1):
0: Switch on set value generation only when drive enabled
a)
1: Always switch on set value generation
a)
Drive state P108.6 = 4 ("Operation Enabled")
2 0: Looped operation: the set value generator starts again with the first set
value after the last phase has elapsed.
1: Single cycle: the generator runs through only one cycle of the preset set
value profile. At the end, the last set value is held.
31…3 Reserved
