3.8.9.4 Description of the Parameter
166.1 Mode
The mode can only be changed if the controller is not enabled. 
166.2 State
Bit no. Meaning
1 ... 0 Mode for U-f characteristic
0: Simple U-f characteristic without overcurrent protection
1: Simple U-f characteristic with overcurrent protection
2: Compensating controller for acceleration
2 Reserved
3 Current control for low speed
0: Inactive
1: Active
4 0: Increase of frequency via slip compensation
1: Compensating controller for frequency with speed controller
5 0: Ramp-up via S-curve
1: Ramp-up linear
6 0: Set value via Z166.6– (Input reference frequency)
1: Set value via ramp function generator
7 Frequency reduction:
0: Inactive
1: Active
8 Current set value
0: Current threshold motor/generator (Z166.3– / Z166.4–)
1: Current setting (Z133.22–)
15 ... 9 Reserved
Bit no. Meaning
0 Acceleration
0: negative direction of revolution
1: positive direction of revolution
1 Braking
2 Set value reached
3 Reserved
4 Positive limit of acceleration
5 Negative limit of acceleration
