Controllers
Parameter manual b maXX BM5800
Document No.: 5.16029.03 Baumüller Nürnberg GmbH
486
of 814
3.7
Figure 127: Block diagram: Effect of field weakening factor ASM
Figure 128: Block diagram: Effect of field weakening factor SM
X
100%

ASM:
-1
-1
5000_0320_rev03_int.cdr
X
Field weakening at voltage limit (142.1 Bit0=0):
Field weak factor
142.2
Flux set value
[%]
146.13
Flux controller
External limiting max field
current amplitude,138.10
Isd set value
47.2
Permanent field current (142.1 Bit0=1):
Field current preset value 19.9
External limit max field
current amplitude,138.10
Limit magnetizing current
146.12
Isd set value
47.2
Actual flx
[%]
Limit magnetizing current
146.12
Lh characteristic
1/Flux nom [Vs]
Flux set value
[%]
146.13
X
1

SM:
-1
5000_0345_rev01.cdr
-1
Field weakening at voltage limit (142.1 bit0=0):
Field weak factor
142.2
Field current
preset value
19.9
External limiting max field
current amplitude 138.10
Isd set value
47.2
Permanent field weakening current (142.1 bit0=1):
Isd set value
47.2
External limiting max field
current amplitude 138.10
Field current preset value 19.9
