Error messages and troubleshooting
Parameter manual b maXX BM5800
Document No.: 5.16029.03
737
of 814
4
410 Undervoltage EnDat
interface The error is triggered by the module EnDat
interface when the
absolute encoder reports via the EnDat
interface that the supply
voltage is too low.
m Cause:
Cause for a encoder supply voltage that is too low may be cor-
roded contacts
n Remedy:
Check encoder cable
m Cause:
Cause can also be a defect in the encoder hardware.
n Remedy:
Replace encoder.
Pulse block
411 Overcurrent EnDat
interface The error is triggered by the module EnDat
interface when the
absolute encoder reports via the EnDat
interface that the encoder
supply current is too high.
m Cause:
Cause for a encoder supply current that is too high may be an
internal short circuit.
n Remedy:
Replace encoder.
Pulse block
412 Battery error EnDat
interface The error is triggered by the module EnDat
interface when the Mul-
titurn absolute encoder reports via the EnDat
interface that the
supply battery must be replaced. The battery voltage provides posi
-
tion information for the Multiturn encoder in the memory when the
controller is switched off and no supply voltage is provided for the
encoder.
m Cause:
Cause for a battery replacement in the Multiturn encoder may be
a modification of the battery.
n Remedy:
Replace encoder.
Pulse block
413 Alarm Bit set EnDat
interface has set alarm Bit (collective message). Pulse block
414 Error during reception: Address mirror-
ing returns an error
Error during reception: Address mirroring returns an error Pulse block
415 Variance of encoder signals exceeds
adjustable limit
The variance of encoder signals exceeds adjustable limit Pulse block
416 Touch probe: trigger zero pulse without
incremental encoder
The touch probe measurement is configured to trigger by a zero
pulse, but the used encoder does not provide a zero pulse.
m Effect:
Value is not accepted
Response parameterizable
n Acknowledgment:
No particular action
No response
417 Warning Collision of frequency EnDat
encoder has messaged warning collision of frequency, see
Z137.38–; preventative maintenance is recommended.
No response
418 Warning Excess temperature EnDat
encoder has messaged warning excess temperature; see
Z137.38– and error number 407; preventative maintenance is rec-
ommended.
No response
419 Warning Lighting controller reserve
reached
EnDat
encoder has messaged warning „Lighting controller reserve
reached“; see
Z137.38– and error number 406; preventative main-
tenance is recommended in order to avoid lighting failure.
No response
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
