Install RAD Technology Components | 51
Install RAD Technology Components
Perform these installation steps for the RAD technology Peri-pump dispenser, if
applicable. Otherwise, skip this section.
RAD™ Tech-
nology Com-
ponents
1 - Secondary
or external
Peri-pump
2 - RAD
dispense head
(with ribbon
cable)
3 - RAD
module and
thumbscrew
4 - Tubing
bracket
5 - Cables (2)
RAD technology uses the secondary or external Peri-pump dispenser, a tubing
bracket, and a dedicated dispense head. After removing and storing the shipping
hardware, install these components:
l Install the Secondary Peri-Pump on page 46
l Install the Tubing Bracket and RADModule below
l RAD: Plug in the cables on page 53
l Install RAD Dispense Head on page 53
l Install RAD Technology Cassette on page 58
Install the Tubing Bracket and RADModule
First, install the tubing bracket and then attach the small RAD module with a serial
port to the bracket.
