Set up the Strip Washer | 37
The washer module functions as a shelf for a Syringe dispenser, if desired.
Install the tubing bracket
A stainless steel bracket to keep the tubing away from
moving devices is provided with the washer and RAD
models.
Attach the bracket to the back of the instrument: near the
top, center of the instrument, slightly left of the aluminum
mounting plate as you face the back panel.
You need a small Philips screwdriver.
1. First, remove the two screws you will use to attach
the bracket. Refer to the photo below to locate the
screws on the back of the instrument.
2. Align the bracket to the holes and use the screws to
attach it.
