76 | Chapter 2: Installation
8-tube Dual 8-tube manifolds in a single block.
16-tube 16-channel.
32-tube 1536-well plates only;
Model: Large Bore (LB) or Small Bore (SB).
8-tube 6-well plates only; 4 tubes per well.
9-tube 12-well plates only; 3 tubes per well.
8-tube 24-well plates only; 2 tubes per well.
12-tube 48-well plates only; 2 tubes per well.
3. LHC: Click Send to send this setting to the instrument.
Change the cassette type setting
The Peri-pump Cassette Type setting must be correct.
Note: Internal and External Peri-pump Dispensers: When the MultiFlo FX has an internal
or built-in peristaltic pump it is called the Primary Peri-pump and an external pump is
called the Secondary Peri-pump. When an instrument has only one pump, either internal
or external, it is called Primary.
LHC Touch screen
1. Select Tools>Instrument
Utilities
2. Select the Peri-pump tab.
3. Select the correct button for the
Cassette Type installed for the
primary or secondary Peri-
pump, if applicable.
4. Click Send to update the
instrument.
1. From the home screen, select
Instrument>Peri-pump.
2. Select the Cassette Type for
each dispenser: Primary and
Secondary, as applicable.
Tip: You may want to employ the Cassette Requirement Mode feature (as described
on page 158) to automatically update the instrument's Cassette Type setting when you run
a protocol. For advanced users with well organized procedures, the MultiFlo FX provides the
ability to change the cassette type setting on-the-fly. It uses the "Require a specific
cassette" parameter in a Peri-pump step to automatically change the cassette type setting
if it does not match the required cassette.
MultiFlo™ FX Multi-Mode Dispenser
