Product Overview > Name of Parts > Control Panel > MF4890dw/MF4880dw/MF4830d/MF4820d
Product Overview > Name of Parts > Control Panel > MF4890dw/MF4880dw/MF4830d/MF4820d
■
Printer
●
MF4780w/MF4770n/MF4750/MF4730/MF4720w/MF4712/MF4710
[10]
[1]
[11]
[2]
[12]
[3] [4] [5]
[6][7][8][9]
No. Name No. Name
[1] Fixing Pressure Roller [7] Multi-Purpose Tray
[2] Fixing Film Unit [8] Photosensitive Drum
[3] Delivery Roller [9] Pickup Roller
[4] Fixing Assembly [10] Separation Pad
[5] Laser Scanner Unit [11] Feed Roller
[6] Pickup Tray [12] Transfer Roller
F-1-15
Control Panel
■
MF4890dw/MF4880dw/MF4830d/MF4820d
F-1-16
