Service Mode > TESTMODE > FAX > MODEM
Service Mode > TESTMODE > FAX > MODEM
■
ADFTEST
TESTMODE>SCAN>ADFTEST
Sub item Description
Single-sided
ADF model
Double-sided
ADF model
SPEED For testing of ADF feeding speed. Execute
feeding test of ADF motor at specied speed.
[Setting value]
STD-FAX
Fine-FAX
SFine-FAX
RGB-600dpi
RGB-300dpi
RGB-150dpi
Gray600dpi
Gray300dpi
Gray150dpi
Mono600dpi
Mono300dpi
Mono150dpi
Yes Yes
2-SIDE Specify ON/OFF for duplex mode Yes
COUNT Page counter for originals: Existing Yes Yes
START Start feeding Yes Yes
■
BOOKFEED
TESTMODE>SCAN>BOOKFEED
Sub item Description
SPEED For testing of feeding speed. Execute feeding test of the book motor at specied
speed.
[Setting value]
STD-FAX
Fine-FAX
SFine-FAX
RGB-600dpi
RGB-300dpi
RGB-150dpi
Gray600dpi
Gray300dpi
Gray150dpi
Mono600dpi
Mono300dpi
Mono150dpi
PAGE Display the number of bookfeed pages
START Start of bookfeed
STOP End of bookfeed
T-8-46
T-8-47
FAX
■
MODEM
TESTMODE>FAX>MODEM
Sub item Description FAX model only
FREQ Transmit selected frequency in closed DC circuit using tone
generation function of modem.
[Setting values]
462Hz
1100Hz
1300Hz
1500Hz
1650Hz
1850Hz
2100Hz
Yes
G3TX Transmit selected signal pattern in closed DC circuit at
selected frequency using G3 signal transmission function of
modem.
[Setting values]
300bps
2400bps
4800bps
7200bps
9800bps
TC7200
TC9600
12000bp
14400bp
Yes
DTMFTX(LONG) Transmit DTMF signal using DTMF transmission function of
modem after DC circuit closure.
Yes
V34G3TX Transmit selected frequency using G3 signal transmission
function (V.34) after DC circuit closure.
[Setting values]
SPEED
3429baud
3200baud
3000baud
2800baud
2743baud
2400baud
Yes
T-8-48
