Service Mode > FEEDER > FUNCTION
Service Mode > FEEDER > FUNCTION
FEEDER
ADJUST
FEEDER>ADJUST
Sub item Description ADF model only
DOCST Adjustment of the page front reading position when
using ADF(common in SADF model and DADF model)
Setting range: -30 ~ 30
Yes
LA-SPD Adjustment of magnication ratio in vertical scanning
direction in stream feeding
Setting range: -200 ~ 200
Yes
FUNCTION
FEEDER>FUNCTION
Sub item Description ADF model only
FEED-CHK Paper feeding test for only ADF
Setting value 1: SADF 2:DADF
Yes
SL-ON Operation start-up for solenoid Yes
MTR-ON Operation start-up for motor Yes
FEED-ON Paper feeding test for only ADF Yes
T-8-19
T-8-20
