Service Mode > FAX > List of Menu
Service Mode > FAX > List of Menu
FAX>SSSW
SSSW No. Bit No. Function
SW 22
Bit 0 Prohibit NSX transmission
Bit 1 Prohibit separated A4 record
Bit 2 Prohibit broadcasting transmission
Bit 3 Prohibit manual polling actions
Bit 4 Prohibit manual transmission when transmitting archives
Bit 6 With archive transmission function
SW 23-SW 24
Not in use
SW 25 (Setting for report display function)
Bit 0 Prioritize the received telephone number to the dialed number
Bit 1 Prioritize the received abbreviated name to the dialed abbreviated name
Bit 2 Regard a received blank CIS as an unreceived CIS
Bit 3 Message language selection for user SW
SW 26-SW 27
Not in use
SW 28
Bit 0 Prohibit calling party for V8 procedure
Bit 1 Prohibit called party from V8 procedure
Bit 2 Prohibit calling party from V8 late-start
Bit 3 Prohibit called party from V8 late-start
Bit 4 Prohibit V.34 called party from starting fallback
Bit 5 Prohibit V.34 calling party from starting fallback
SW 29
Not in use
SW 30
Bit 0 Support for 1284 device ID
Bit 5 New dial tone detection method
SW 31
Not in use
SW 32
Bit 0 Canon/NTT NSX switching SW
Bit 5 0:NCU2004 1:NCU2002
SW 33-SW 50
Not in use
T-8-21
List of Menu
• FAX model only
Menu switch registration mode
No. Parameter Selection
01-04
Not in use
05
ON/OFF of NL equalizer 0: OFF 1: ON
06
Telephone line monitor 0-3
0: DIAL
1: SERVICEMAN 1
2: SERVICEMAN 2
3: OFF
07
Transmission level (ATT) 0-15
08
Upper limit of V.34 modulation speed 0-5
0: 3429BAUD
1: 3200BAUD
2: 3000BAUD
3: 2800BAUD
4: 2743BAUD
5: 2400BAUD
09
Upper limit of V.34 data speed 0-13
0: 33.6kbps, 1:31.2,
2: 28.8, 3: 26.4, 4: 24.0,
5: 21.6, 6: 19.2, 7: 16.8,
8: 14.4, 9: 12.0, 10: 9.6,
11: 7.2, 12: 4.8, 13: 2.4
10
Pseudo-CI signal frequency 0-2
0: 50Hz, 1: 25Hz, 2: 17Hz
11-20
Not in use
T-8-22
