Canon imageCLASS D530 - Copier; Display; CCD; Version

8
8
8-3
8-3
Service Mode > COPIER > I/O > R-CON
Service Mode > COPIER > I/O > R-CON
COPIER
DISPLAY
■
VERSION
COPIER>DISPLAY>VERSION
Sub item Description
MAIN Display version/checksum/date of Bootable (Product program area)
ECONT Display ROM version of recording engine
■
CCD
COPIER>DISPLAY>CCD
Sub item Description
Common to
all models
ADF model
only
FB-TARGET-B Shading target value for BLUE of Reader Copyboard Yes
FB-TARGET-G Shading target value for GREEN of Reader Copyboard Yes
FB-TARGET-R Shading target value for RED of Reader Copyboard Yes
FB-TARGET-BW Shading target value of Reader Copyboard in black
and white
Yes
DF-TARGET-B Shading target value for BLUE of DF Yes
DF-TARGET-G Shading target value for GREEN of DF Yes
DF-TARGET-R Shading target value for RED of DF Yes
DF-TARGET-BW Shading target value of DF in black and white Yes
T-8-1
T-8-2
I/O
■
R-CON
COPIER>I/O>R-CON
Address BIT Contents of display
P001 0 Sensor state display (DES)
1 Sensor state display (DS)
T-8-3
