Canon imageCLASS D530 - Auto; Cng Detect; Reorder Tone; Rkey

8
8
8-13
8-13
Service Mode > FAX > List of NCU > RKEY
Service Mode > FAX > List of NCU > RKEY
(2) Numeric value parameter
Parameter No. Function Setting range
01;
02;
T1 timer 0 to 9999 (x10ms)
03;
T2 timer 0 to 9999 (x10ms)
04;
T3 timer 0 to 9999 (x10ms)
05;
T4 timer 0 to 9999 (x10ms)
06;
Signal detection table 0 to 16
07;
Signal detection level 0 to 7
08;
Number of valid tone detection 0 to 9999 (times)
■
REORDER TONE
(1) Bit switch
Bit No. Function 1 0
Bit 0
Bit 1
Signal detection method FED FR3
Bit 2
Signal frequency Changed Not changed
Bit 3
Bit 4
Judgment of intermittent signal Start from valid ON
signal
Start from either valid
ON signal or OFF signal
Bit 5
Bit 6
Signal form Continuous Intermittent
Bit 7
Signal detection Detected Not detected
(2) Numeric value parameter
Parameter No. Function Setting range
01;
02;
T1 timer 0 to 9999 (x10ms)
03;
T2 timer 0 to 9999 (x10ms)
04;
T3 timer 0 to 9999 (x10ms)
05;
T4 timer 0 to 9999 (x10ms)
06;
Signal detection table 0 to 16
07;
Signal detection level 0 to 7
08;
Number of valid tone detection 0 to 9999 (times)
T-8-32
T-8-33
T-8-34
■
AUTO RX
(1) Numeric value parameter
Parameter No. Function Setting range
01;
CI ON time 0 to 9999 (x10ms)
02;
Cl long off time 0 to 9999 (x10ms)
03;
Cl off time 0 to 9999 (x10ms)
04;
CL long off time 0 to 9999 (x10ms)
05;
Cl MAX off time 0 to 9999 (x10ms)
06;
Cl wait time 0 to 9999 (x10ms)
07;
CI frequency 0 to 9999 (cycle)
08;
CI frequency lower limit 0 to 9999 (Hz)
09;
CI frequency upper limit 0 to 9999 (Hz)
■
CNG DETECT
(1) Numeric value parameter
Parameter No. Function Setting range
01;
At F/T switching CNG MIN ON time 0 to 9999 (x10ms)
02;
CNG MAX ON time 0 to 9999 (x10ms)
03;
04;
05;
06;
Hit ratio 0 to 9999 (%)
07;
At direct
connecting to
answering phone
CNG MIN ON time 0 to 9999 (x10ms)
08;
CNG MAX ON time 0 to 9999 (x10ms)
09;
Tolerable time of
instantaneous
interruption
0 to 9999 (x10ms)
10;
11;
Number of detection 0 to 9999 (Times)
12;
Hit ratio 0 to 9999 (%)
■
RKEY
(1) Numeric value parameter
Parameter No. Function Setting range
01;
Connection time of ash 0 to 9999 (x10ms)
02;
Connection time of grounding wire 0 to 9999 (x10ms)
03;
T-8-35
T-8-36
T-8-37
