Disassembly/Assembly > List of Parts > Duplex Printer Unit > Lists of Motor/Fan
Disassembly/Assembly > List of Parts > Duplex Printer Unit > Lists of Motor/Fan
■
Lists of Reader Unit
[1]
[2]
No. Name Reference Remarks
[1] CIS Sensor -
[2] Reader Motor -
F-4-3
Duplex Printer Unit
■
Lists of Motor/Fan
[1]
[2]
[3]
No. Name Reference Remarks
[1] Main Motor -
[2] Main Fan Unit -
[3] Laser Scanner Unit -
F-4-4
