Service Mode > FAX > List of NCU > BUSY TONE1
Service Mode > FAX > List of NCU > BUSY TONE1
(2) Numeric value parameter
Parameter No. Function Setting range
01;
T0 timer 0 to 9999 (x10ms)
02;
T1 timer 0 to 9999 (x10ms)
03;
T2 timer 0 to 9999 (x10ms)
04;
T3 timer 0 to 9999 (x10ms)
05;
T4 timer 0 to 9999 (x10ms)
06;
Signal detection table 0 to 16
07;
Signal detection level 0 to 7
08;
Number of valid tone detection 0 to 9999 (times)
■
2nd DIAL TONE
(1) Bit switch
Bit No. Function 1 0
Bit 0
Frequency detection method Modem Tonal counter
Bit 1
Bit 2
Signal frequency Changed Not changed
Bit 3
Bit 4
Judgment of intermittent signal Start from valid ON
signal
Start from either valid
ON signal or OFF signal
Bit 5
Bit 6
Signal form Continuous Intermittent
Bit 7
Signal detection Detected Not detected
(2) Numeric value parameter
Parameter No. Function Setting range
01;
T0 timer 0 to 9999 (x10ms)
02;
T1 timer 0 to 9999 (x10ms)
03;
T2 timer 0 to 9999 (x10ms)
04;
T3 timer 0 to 9999 (x10ms)
05;
T4 timer 0 to 9999 (x10ms)
06;
Signal detection table 0 to 16
07;
Signal detection level 0 to 7
08;
Number of valid tone detection 0 to 9999 (times)
T-8-26
T-8-27
T-8-28
■
BUSY TONE0
(1) Bit switch
Bit No. Function 1 0
Bit 0
Bit 1
Bit 2
Signal frequency Changed Not changed
Bit 3
Bit 4
Judgment of intermittent signal Start from valid ON
signal
Start from either valid
ON signal or OFF signal
Bit 5
Bit 6
Signal form Continuous Intermittent
Bit 7
Signal detection Detected Not detected
(2) Numeric value parameter
Parameter No. Function Setting range
01;
02;
T1 timer 0 to 9999 (x10ms)
03;
T2 timer 0 to 9999 (x10ms)
04;
T3 timer 0 to 9999 (x10ms)
05;
T4 timer 0 to 9999 (x10ms)
06;
Signal detection table 0 to 16
07;
Signal detection level 0 to 7
08;
Number of valid tone detection 0 to 9999 (times)
■
BUSY TONE1
(1) Bit switch
Bit No. Function 1 0
Bit 0
Bit 1
Bit 2
Signal frequency Changed Not changed
Bit 3
RBT signal detection Detected Not detected
Bit 4
Judgment of intermittent signal Start from valid ON
signal
Start from either valid
ON signal or OFF signal
Bit 5
RBT signal check cycle 1 cycle 1/2 cycle
Bit 6
Signal form Continuous Intermittent
Bit 7
Signal detection Detected Not detected
T-8-29
T-8-30
T-8-31
