Disassembly/Assembly > Pickup And Feeding System > Removing the Pickup Tray Unit (D530) > Procedure
Disassembly/Assembly > Pickup And Feeding System > Removing the Pickup Tray Unit (D530) > Procedure
Caution:
Align the 2 boss holes [1], 2 hooks [2] and 2 bosses [3] of the pickup tray unit with the
pickup unit to mount the unit.
[1]
[1]
[2]
[2]
[3]
Caution:
When assembling the pickup tray unit, check the positioning of the 6 bosses [1] in the
unit.
[1]
