Misformed image
Image is misformed
Cause Solution
1) Poor contact exists to the connector on the
laser scanner unit
Reconnect the connectors: J12 and J100
2) Poor contact exists to the connector on the
Main Controller
Reconnect the connectors: J1505 and J1702
3) The laser scanner unit is defective Replace the laser scanner unit.
■
Repetitive image defects ruler
Component Distance
between
defects (mm)
Image defects
Dirt Dropouts Dirt on back Loose toner
Registration roller About 44 ○ ○
Primary charging roller About 38 ○ ○
Photosensitive drum About 94 ○ ○
Developing roller About 50 ○ ○
Transfer roller About 43 ○ ○
Fixing lm unit About 76 ○ ○ ○
Pressure roller About 77 ○ ○
