Service Mode
Entering Service Mode
Contact the sales company for the method to enter service mode.
Service Mode List (LBP3560/6750dn)
■
OPTION.GR
Item Description Setting Range
B4-L-CNT Set to determine B4 size to be large size or small size. ON/OFF*
• ON: B4 size is to be large size.
• OFF: B4 size is to be small size.
SCT-ALL-CLR Set to determine whether “Clear All Counts” can be executed
from “Department ID Management” screen on RUI.
ON*/OFF
• ON: “Clear All Counts” can be executed.
• OFF: “Clear All Counts” cannot be executed.
SCT-IDV-CLR Set to determine whether “Clear Count” can be executed from
“Edit Department” screen on RUI.
ON*/OFF
• ON: “Clear Count” can be executed.
• OFF: “Clear Count” cannot be executed.
PS-MODE Set for the EFI compatibility at PS duplex delivery and the
function to change the Stroke Adjustment default value.
0 to 65535
(increment by 1)
• Bit 7: When the setting is ON, the conversion curve line for
Type 3 dither is reversed (embossed arch line).
• Bit 6: When the setting is ON, 16 × 16 size dither (used for
BW2) is used.
• Bit 5: When the setting is ON, duplex print of the same paper
size with Portrait and Landscape mixed is performed.
• Bit 4: When the setting is ON, the default value of Stroke
Adjustment is to be TRUE. By doing so, uneven line width
based on the coordinates can be changed to even line width.
COUNTER-SW
*1
Set the counter switch. MODEL1*/
MODEL2
• MODEL1: Setting value 1
• MODEL2: Setting value 2.
*1:Supporting the North America models with the charge counter only
■
FUNCTION GR.
Item Description Setting Range
ECONF EXPORT Export unit setting data GENERAL/DEPEND/SECURITY/ALL
IMPORT Import unit setting data ----
T-5-33
T-5-34
■
LOG GR.
Item Description Setting Range
SYSTEM LOG Select system log setting ON*/OFF
SUBLOG FTP GET Get SUBLOG without using serial console ----
LOGGING UTILITY Select whether to use "Logging Utility" from Utility menu ON/OFF*
ON: Logging utility function enabled
OFF: Logging utility function disabled
■
F/W UPDATE GR.
Item Description Setting Range
USB Update controller rmware version (only USB is supported) ----
NETWORK Execute version upgrade of controller rmware ----
■
NETWORK GR.
Item Description Setting Range
DNSTRANS Priority of protocol for DNS inquiry (IPv4/IPv6) IP V. 4/IP V. 6*
FTP SYSLOG Setting for obtaining system log les by ftp ON/OFF*
JOB SERIALIZE Connection serialize function setting ON/OFF*
BUFFER LIMIT PSS buffer limit cancel setting ON/OFF*
T-5-35
T-5-36
