Troubleshooting > Service Mode > Service Mode List (LBP3560/6750dn) > SP.ADMIN.MODE
Troubleshooting > Service Mode > Service Mode List (LBP3560/6750dn) > SP.ADMIN.MODE
Item Description Setting Range
E-RDS E-RDS SWITCH Set to determine whether Embedded-
RDS is used.
ON/OFF*
• ON: Embedded-RDS is used.
• OFF: Embedded-RDS is not used.
RGW-ADDRESS URL can be checked and set here. For
the URL entry, use various keys (up/
down/left/right keys, Job Status/Cancel
key and Feeder Selection key). Then,
press OK key to set the entry. In the
very end of character strings, “down-
pointing arrow” is displayed. Up to 128
characters can be entered.
----
RGW-PORT Set the port number of server. ----
COM-TEST Communication test is executed. The
machine tries to connect to the server,
judges whether it was connected, and
displays the result.
----
COM-LOG Details of communication test result are
displayed. When any error occurs, the
time, error code and error information
are displayed. Up to 5 logs can be
stored and the latest log is displayed
----
CREAR Beside e-RDS setting value in the
service mode, schedule information,
alarm and ltering information are
cleared.
----
CA-KEY CREAR After executing this item, turn the power
OFF/ON t o set the CA certicate to the
default status.
----
MIB
CHARGECOUNT
• ALL ACCESS: All information in the charge counter MIB
can be collected.
ALL ACCESS*/
DISP ACCESS/
NON ACCESS
• DISP ACCESS: Information displayed on LUI in the
charge counter MIB is displayed.
• NON ACCESS: All information in the charge counter MIB
cannot be collected.
SNMP canon_admin OFF: canon_admin community disabled OFF
READ ONLY: canon_admin community
enabled. MIB access is Read Only
ReadOnly
READ WRITE: canon_admin
community enabled. MIB access is
Read/Write
ReadWrite*
canon_user OFF: canon_user community disabled OFF
READ ONLY: canon_user community
enabled. MIB access is Read Only
ReadOnly
READ WRITE: canon_user community
enabled. MIB access is Read/Write
ReadWrite*
Item Description Setting Range
TCP DELAYED ACK ON: TCP ACK delay function enabled ON*/OFF
OFF: TCP ACK delay function disabled
WOLtrans 1: New protocol (WSD) WakeUp enabled; old utility
WakeUp function using CPCA Echo (broadcast) packets not
supported.
1* – 3
2: New protocol (WSD) WakeUp enabled; old utility WakeUp
function using SNMP search broadcast packets not
supported.
3: Old Canon utility WakeUp function supported; new
protocol (WSD) WakeUp function not supported.
SLEEP ADVERTISE SWITCH Determines whether sleep advertise
function is used
ON*/OFF
PORT Species port number for sleep
advertise function
1 – 11427* –
65535
TTL Sets number of routers exceeding
sleep advertise message number
0 – 3* – 254
INTERVAL Sets sleep advertise interval (seconds) 60 – 600* –
65535
■
SP.ADMIN.MODE
Item Description Setting Range
MAINTENANCE C. Not used -
T-5-37
T-5-38
