Service Mode List (LBP3580/6780x)
■
ADJUST.GR
Item Description Setting Range
ENGINE DENSITY
CORR.
Function to execute density correction by setting the
developing bias on the engine side
-7 (-4) to -3* (0*)
to 8 (11)
SCM value
(Displayed
value)
SUBTLE DENSITY
CORR.
Function to adjust ne density at 1200pdi -1 to 0* to 1
• "*" indicates factory default setting.
■
OPTION.GR
Item Description Setting Range
B4-L-CNT Set to determine B4 size to be large size or small size. On* , Off
• ON: B4 size is to be large size.
• OFF: B4 size is to be small size.
SCT-ALL-CLR Set to determine whether “Clear All Counts” can be executed
from “Department ID Management” screen on RUI.
On* , Off
• ON: “Clear All Counts” can be executed.
• OFF: “Clear All Counts” cannot be executed.
SCT-IDV-CLR Set to determine whether “Clear Count” can be executed from
“Edit Department” screen on RUI.
On* , Off
• ON: “Clear Count” can be executed.
• OFF: “Clear Count” cannot be executed.
PS-MODE Set for the EFI compatibility at PS duplex delivery and the
function to change the Stroke Adjustment default value.
0* to 65535
• Bit 7: When the setting is ON, the conversion curve line for
Type 3 dither is reversed (embossed arch line).
• Bit 6: When the setting is ON, 16 × 16 size dither (used for
BW2) is used.
• Bit 5: When the setting is ON, duplex print of the same paper
size with Portrait and Landscape mixed is performed.
• Bit 4: When the setting is ON, the default value of Stroke
Adjustment is to be TRUE. By doing so, uneven line width
based on the coordinates can be changed to even line width.
COUNTER-SW
*1
Set the counter switch. MODEL1* ,
MODEL2
• MODEL1: Setting value 1
• MODEL2: Setting value 2.
• "*" indicates factory default setting.
T-5-39
T-5-40
■
FUNCTION GR.
Item Description Setting Range
ECONF EXPORT Export unit setting data GENERAL , DEPEND
, SECURITY , ALL
IMPORT Import unit setting data USB-H , On , Off*
USB-H To set to enable/disable the USB host function.
By turning ON the host function, USB memory can be
used.
On , Off*
SUBLOG TO
USE
Output a sub log to the USB memory. -
