General Timing Chart
■
General Timing Chart
Two consecutive prints on LTR paper
YBTSRTSLTNIRPRTNIYBTSTIAW
23
21
22
19
20
17
18
15 Main fan (FM1)
16 Sub fan (FM2)
13 Transfer charging bias
14 Fixing bias
11 Primary charging bias
12 Developing bias
9 Fixing motor (M8002)
10 Fixing heater
7 Scanner motor (M3)
8 Main motor (M8001)
5 BD signal
6 VIDEO signal
3 TOP sensor (PS215)
4 Fixing delivery sensor (PS2)
1 Print start command (EEC12)
2 Cassette pickup solenoid (SL2)
Power ON
F-6-1
