Cisco ASR 1001 Hardware Installation Guide

+3.3 V+12 VDCOutput Voltage
3.30 VDC12.00 VDCNominal
3.40 VDC12.20 VDCMaximum
Output Current
0.10 A2.80 AMinimum
3.125 A61.44AMaximum
Power Supplies for the Cisco ASR 1002 Router
Unless otherwise noted, the Cisco ASR 1002-F Router and the Cisco ASR 1002-X Router supports all
the general-purpose routing and security features of the Cisco ASR 1002 Router and uses the same internal
control and data-plane architecture as Cisco ASR 1002 Router. The Cisco 24 V power supply is currently
supported only on the Cisco ASR 1002 Router and the Cisco ASR 1002-X Router but not on the Cisco
ASR 1002-F Router.
Note
The Cisco ASR 1002 Router supports an AC or –48 VDC power supply and a +24 VDC power supply:
Cisco ASR 1002 Router Power Supply Fans
Cisco ASR 1002 Router system level cooling is provided by two 12 VDC type fans in each power supply
module. The fans in each module provide system cooling back-up in the event of a single fan failure. In
addition, the fans in each of the power supplies can be powered from a single supply when only one unit is
operational. The airflow direction is front to back.
This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the
protective device is rated not greater than: AC power supplies for the Cisco Aggregation Services Routers:
120 VAC, 20A U.S. maximum. DC power supplies for the Cisco ASR 1006 Router: 50A U.S. maximum;
Cisco ASR 1004 Router: 40A U.S. maximum: Cisco ASR 1002 Router: 30A U.S. maximum. Statement
1005
Warning
Cisco ASR 1002 Router AC Power Supply
This section provides information about the AC power supplies on the rear of the Cisco ASR 1002 Router.
The Cisco ASR 1002 Router system level cooling is provided by two 12 VDC type fans in each of the two
power supply modules. The fans in each module are intended to provide system cooling back-up in the event
of a single fan failure. In addition, the fans in each of the power supplies can be powered from a single supply
when only one unit is operational. The airflow direction is front to back. The power supplies plug directly
into the Cisco ASR1000-RP1 and distributes power back to the midplane.
Cisco ASR 1000 Series Router Hardware Installation Guide
66
Cisco ASR 1000 Series Routers Component Overview
Power Supplies for the Cisco ASR 1002 Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
