Cisco ASR 1001 Hardware Installation Guide

Warning Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning This unit is intended for installation in restricted access areas. A restricted access area can be accessed
only through the use of a special tool, lock and key, or other means of security. Use when a product has an
accessible HAZ/V circuits or a DC supply that is not provided with a field wiring cover. Statement 1017
Related Documentation
Your Cisco ASR 1000 Series Routers and the Cisco IOS software running on it contain extensive features
and functionality, which are documented in the following resources:
•
All documentation related to the Cisco ASR 1000 Series Routers is listed in the online Cisco ASR 1000
Series Aggregation Services Routers Documentation Roadmap . Information in this master index includes
troubleshooting tools and documentation, regulatory compliance and safety information, and installation
and replacement information. Also see the Cisco ASR 1000 Series Port Adapter Documentation Roadmap
for specific shared port adapters supported on the Cisco ASR 1000 Series Routers.
Some of the Cisco ASR 1000 Series Routers documentation that is listed on the Cisco ASR 1000 Series
Aggregation Services Routers Documentation Roadmap includes:
•
Quick Start Guides for the Cisco ASR 1000 Series Routers. These guides provide quick reference
information about chassis or parts installation procedures.
◦
Cisco ASR 1000 Series Router Hardware Installation Guide
xxxiii
Preface
Related Documentation

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
