Cisco ASR 1013 Router Memory and Storage Options
The following table lists the hardware memory and storage options supported on the Cisco ASR 1013 Router.
Table 119: Memory and Storage Options for Cisco ASR 1013 Router
Maximum System SupportDefaultMemory Type
8 GB8 GB
R21– DRAM
2 GB1 GB for ASR1000-ESP-5
2 GB for ASR1000-ESP10
FECP – DRAM
8 GB – Not Field Upgradeable
8 GB on the integrated RP on the Cisco
ASR 1002 Router (partitioned: 1 GB for
bootflash; 7 GB for mass storage)
eUSB – Internal Flash + NVRAM
Cisco ASR 1013 Router Ethernet RJ-45 Port Pinouts
The Cisco ASR 1013 Router has RJ-45 port for the 10/100/1000 Ethernet connections. The RJ-45 port supports
IEEE 802.3ab (Gigabit Ethernet) and IEEE 802.3u (Fast Ethernet) interfaces compliant with 10BASET,
100BASETX, and 1000BASET specifications.
The RJ-45 port supports standard straight-through and crossover Category 5 UTP cables with RJ-45 connectors.
Cisco does not supply Category 5 UTP cables; these cables are available commercially.
Cisco ASR 1013 Router MGMT Ethernet Port Signals and Pinouts
The following table lists the RJ-45 port pinout for the front panel Management Ethernet port.
Table 120: Management Ethernet 10/100/1000 RJ-45 Port Pinouts for Cisco ASR 1013 Router
DescriptionDirectionSignalPin
Transmit DataOutputTX Data+1
Transmit DataOutput
TX Data–
2
Receive DataInputRX Data+3
——
NC4, 5
Receive DataInput
RX Data–
6
——
NC7,8
Cisco ASR 1000 Series Router Hardware Installation Guide
632
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1013 Router Memory and Storage Options

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
