Cisco ASR 1001 Hardware Installation Guide

AWG # WireCircuit Breaker
Amps
System Input Rating
(Amps)
Cisco ASR 1000
Series Router DC
Power Supply
For example, the
Cisco ASR 1002
Router DC power
supply, with 16
Amp input rating
must use an AWG
#12 gauge wire for
a 20 A circuit
breaker and an
AWG #10 gauge
wire for a 30 A
circuit breaker.
Power Cords Supported by the Cisco ASR 1006 Router
The following power cords are supported by the Cisco ASR 1006 Router:
• CAB-AC20A-90L-IN—20 A AC right-angle power cord—International
• CAB-4000W-US1—Power cord, 250 VAC 20 A, Right Angle C19, NEMA 6-20 Plug, US
• CAB-US520-C19-US—NEMA 5-15 to IEC-C19 14ft US
The Cisco ASR 1006 Router modular chassis supports redundant power entry modules (PEMs). In the Cisco
ASR 1006 Router, at least one PEM must be functioning. In the event that one of the fans fails, the remaining
fans are sufficient to cool the entire chassis. However, fan speed may have to be increased. For power
consumption specifications, see the “Cisco ASR 1006 Router Specifications” section on page A-1 .
At least one power supply must be powered on before the software is started.Note
All Cisco ASR 1000 Series Router AC power supplies must be connected to a branch circuit that does
not exceed 20 A.
Note
Detailed instructions for removing and replacing the Cisco ASR 1000 Series AC and DC power supplies
are provided in “Removing and Replacing the Cisco ASR 1006 Router Power Supplies” section on page
14-55 .
Note
Connecting AC Input Power to Cisco ASR 1006 Router
Follow these steps to connect an AC-input power supply to the Cisco 1006 chassis:
Cisco ASR 1000 Series Router Hardware Installation Guide
166
Cisco ASR 1006 Router Overview and Installation
Power Cords Supported by the Cisco ASR 1006 Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
