Cisco ASR 1001 Hardware Installation Guide

Table 26: Cisco ASR 1002 Router – 48 VDC Power Supply LEDs
DescriptionColorLEDLED Label
LED illuminates green to signal
that the –48 VDC power supply
input voltage is greater
than–43.5VDC at turn-on and
remains green down to
–39VDC.
GreenA bi-color LED indicates
presence of input voltage
INPUT OK
The LED illuminates amber
when the input voltage (falls
below –39VDC) and indicates
that there is still a voltage
present (voltage on the terminal
block). The LED remains amber
and is active to around 20 V
+/-5 V. The LED is not
illuminated if the input is below
–15 V.
Amber
The LED illuminates s green
when all fans are operational.
GreenA bi-color LED indicates power
supply fan status
FAN OK
The LED illuminates red when
a fan failure is detected.
Red
When the LED is off, it signals
that the –48 VDC output
voltage are within the normal
operating range. Output voltage
between the minimum and
maximum limits will not create
an output fail alarm, and output
voltages below the minimum or
above the maximum will create
an Output Fail alarm.
When you turn the power
supply on, the red LED
illuminates for two to three
seconds to test LED operation
before going off.
RedPower supply activityOUTPUT FAIL
–48 VDC Power System Input for Cisco ASR 1002 Router
The –48 VDC power supply operates within specification from –40.5VDC to –72VDC continuously once the
power supply –48 VDC input turn on threshold of –43.5 V has been reached. The following table shows the
Cisco ASR 1000 Series Router Hardware Installation Guide
70
Cisco ASR 1000 Series Routers Component Overview
Cisco ASR 1002 Router –48 VDC Power Supply

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
