Cisco ASR 1001 Hardware Installation Guide

AC power supply in slot
1 (power supply zone 0)
7Forward rack-mount ears
are shipped installed
2
AC power supply in slot
0 (power supply zone 0)
8Chassis handle3
Chassis ground stud9Rear rack-mount brackets4
——
AC power supply in slot
3 (power supply zone 1)
5
Cisco ASR 1013 Router Power Zones
Internal fans draw cooling air into the chassis and across internal components to maintain an acceptable
operating temperature. (See the preceding figure.) The fans are built into the power supply allowing fan and
power supply replacement. A two-hole grounding lug is located on the bottom rear of the chassis (see the
preceding figure, callout 6). Four power supplies, either AC power supplies or DC power supplies, are accessed
from the rear of the router. The power supply bays are numbered from bottom to top: 0, 1, 2, and 3 respectively.
The Cisco ASR 1013 Router has two power zones:
•
Power zone 1(top half of chassis) includes slots:
◦
PS1-A
◦
PS1-B
◦
Carrier card slots 3, 4, and 5
◦
RP1
◦
FP1
•
Power zone 0 (bottom half of chassis) includes slots:
◦
PS0-A
◦
PS0-B
◦
Carrier card slots 0, 1, and 2
◦
RP0
◦
FP0
Do not combine AC and DC power supplies in the same chassis.Note
Cisco ASR 1013 Router supports only Cisco ASR1000-RP2.Note
Cisco ASR 1000 Series Router Hardware Installation Guide
370
Cisco ASR 1013 Router Overview and Installation
Cisco ASR 1013 Router Power Zones

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
