Cisco ASR 1001 Hardware Installation Guide

AWG # WireCircuit Breaker
Amps
System Input
Rating (Amps)
Cisco ASR 1000
Series Router
DC Power
Supply
For example, the
Cisco ASR 1002
Router –48
VDC power
supply, with 16
Amp input
rating must use
an AWG #12
gauge wire for a
20 A circuit
breaker and an
AWG #10 gauge
wire for a 30 A
circuit breaker.
All Cisco ASR 1000 Series Router AC power supplies must be connected to a branch circuit that does
not exceed 20 A.
Note
Detailed instructions for removing and replacing the Cisco ASR 1000 Series AC and DC power supplies
are in Chapter 14, “Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers.”
Note
Power Cords Supported by the Cisco ASR 1004 Router
Table 51: Power Cords Supported by the Cisco ASR 1004 Router , on page 209 lists the power cords that are
supported by the Cisco ASR 1004 Router.
Table 51: Power Cords Supported by the Cisco ASR 1004 Router
DescriptionPower Cord Item Number
Power Cord, 110 V, Right AngleCAB-AC-RA
10 A AC Power Cord, Left Angle (Australia) (bundle
option)
CAB-AC10A-90L-AU
10 A AC Power Cord, Left Angle (Europe) (bundle
option)
CAB-AC10A-90L-EU
10 A AC Power Cord, Left Angle (Italy) (bundle
option)
CAB-AC10A-90L-IT
Cisco ASR 1000 Series Router Hardware Installation Guide
209
Cisco ASR 1004 Router Overview and Installation
Power Cords Supported by the Cisco ASR 1004 Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
