Cisco ASR 1001 Hardware Installation Guide

•
Always install heavier equipment in the lower half of a rack to maintain a low center of gravity to prevent
the rack from falling over.
•
Install and use the cable-management brackets included with the Cisco ASR 1004 Router to keep cables
organized and out of the way of the cards and processors. Ensure that cables from other equipment
already installed in the rack do not impair access to the cards or require you to disconnect cables
unnecessarily to perform equipment maintenance or upgrades.
•
Install rack stabilizers (if available) before you mount the chassis.
•
Provide an adequate chassis ground (earth) connection for your router chassis.
In addition to the preceding guidelines, review the precautions for avoiding excessive temperature conditions
in the “Site Environmental Requirements” section on page 5-9 .
The following table provides the Cisco ASR 1004 Router dimensions and weight information.
Table 49: Cisco ASR 1004 Router Dimensions and Weight
DimensionsCisco ASR 1004
22.50 in. (57.15 cm)(including card handles,
cable-management brackets, power supply handles).
Depth
6.95 in. (17.653cm) (4 rack-mount per EIA RS-310)Height
17.25 in. (43.815 cm) (19 inch rack- mount or
optional 23 Telco rack-mount)
Width
50 pounds (fully configured)
22.6796 kg
Weight
Guidelines for an Equipment Shelf or Tabletop Installation
The chassis should already be in the area where you will install it. If you have not determined where to install
your chassis, see the “Cisco ASR 1000 Series Routers Component Overview” section on page 2-1 for
information about site considerations.
If you are not rack-mounting your Cisco ASR 1000 series chassis, place it on a sturdy equipment shelf or
tabletop.
When installing the Cisco ASR 1004 Router on an equipment shelf or tabletop, ensure that the surface is clean
and that you have considered the following:
•
The Cisco ASR 1004 Router requires at least 3 inches (7.62 cm) of clearance at the inlet and exhaust
vents (the front and top/rear sides of the chassis).
•
The Cisco ASR 1004 Router should be installed off the floor. Dust that accumulates on the floor is drawn
into the interior of the router by the cooling fans. Excessive dust inside the router can cause
overtemperature conditions and component failures.
•
There must be approximately 19 inches (48.3 cm) of clearance at the front and rear of the chassis to
install and replace FRUs, or to access network cables and equipment.
Cisco ASR 1000 Series Router Hardware Installation Guide
187
Cisco ASR 1004 Router Overview and Installation
Guidelines for an Equipment Shelf or Tabletop Installation

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
