Cisco ASR 1001 Hardware Installation Guide

DescriptionDirectionSignalPin
Receive DataInput
RX Data–
6
——
NC7,8
BITS Interface Port Signals and Pinouts
The following table lists the pinouts of the Building Integrated Timing Supply (BITS) RJ45 port.
Table 128: BITS RJ-45 Receptacle Pinouts for Cisco ASR1000-RP1
DescriptionDirectionSignalPin
Receive RingInputRX Ring1
Receive (T1/E1)InputRX TIP2
——
N/C3, 4
—
UnusedTX Ring5
—
UnusedTX TIP6
——
N/C7,8
Console Port Signals and Pinouts
The following table lists the pinouts of the dual RJ-45 ports for the front panel console port.
Table 129: Console Port Pinouts for Cisco ASR1000-RP1
DescriptionDirectionSignalPin
Request to Send (tied to
pin 8, CTS)
OutputRTS1
Data Terminal Ready
(always On)
OutputDTR2
Transmit DataOutputTXD3
Ring Indicator
—
GND4
——
GND5
Cisco ASR 1000 Series Router Hardware Installation Guide
638
Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
BITS Interface Port Signals and Pinouts

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
