Cisco ASR 1001 Hardware Installation Guide

•
Have experience as electronic or electromechanical technicians.
•
Have experience in installing high-end networking equipment. Certain procedures described in this guide
require a certified electrician.
Document Organization
The following table describes the chapters and appendixes in this installation guide:
DescriptionChapter and Appendix
The preface provides objectives, audience and organization of this manual.Preface
This chapter provides an overview of the Cisco ASR 1000 Series
Aggregation Services Routers.
Chapter 1, “Cisco ASR 1000
Series Routers Hardware
Overview”
This chapter provides an overview of the hardware components for the
Cisco ASR 1000 Series Aggregation Services Routers.
Chapter 2, “Cisco ASR 1000
Series Routers Component
Overview”
This chapter describes the Cisco ESPs for the ASR 1000 platform routers.
Chapter 3, “Cisco ASR 1000
Series Routers Embedded
Services Processors”
This chapter describes the Cisco SIPs for the ASR 1000 platform routers.
Chapter 4, “Cisco ASR 1000
Series Router SPA Interface
Processors (SIPs)”
This chapter provides site preparation guidelines for installing the ASR
1000 Series Routers.
Chapter 5, “Preparing Your Site
for Installation”
This chapter describes the Cisco ASR 1006 router and how to install it.
Chapter 6, “Cisco ASR 1006
Router Overview and
Installation”
This chapter describes the Cisco ASR 1004 router and how to install it.
Chapter 7, “Cisco ASR 1004
Router Overview and
Installation”
This chapter describes the Cisco ASR 1002 router and how to install it.
Chapter 8, “Cisco ASR 1002
Router Overview and
Installation"
This chapter describes the Cisco ASR 1002-F router and how to install it.
Chapter 9, “Cisco ASR 1002-F
Router Overview and
Installation"
Cisco ASR 1000 Series Router Hardware Installation Guide
xxiv
Preface
Document Organization

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
