Cisco ASR 1001 Hardware Installation Guide

•
Allow sufficient clearance around the rack for maintenance. If the rack is mobile, you can push it back
near a wall or cabinet for normal operation and pull it out for maintenance (installing or moving cards,
connecting cables, or replacing or upgrading components). Otherwise, allow 19 inches (48.3 cm) of
clearance to remove field-replaceable units.
•
Maintain a minimum clearance of 3 inches on the front and back sides of the chassis for the cooling air
inlet and exhaust ports, respectively. Avoid placing the chassis in an overly congested rack or directly
next to another equipment rack; otherwise, the heated exhaust air from other equipment can enter the
inlet air vents and cause an overtemperature condition inside the router.
To prevent chassis overheating, never install a Cisco ASR 1001 Router in an enclosed room that is not
properly ventilated or air conditioned.
Caution
•
Always install heavier equipment in the lower half of a rack to maintain a low center of gravity to prevent
the rack from falling over.
•
Install and use the cable-management brackets included with the Cisco ASR 1001 Router to keep cables
organized and out of the way of the cards and processors. Ensure that cables from other equipment
already installed in the rack do not impair access to the cards or require you to disconnect cables
unnecessarily to perform equipment maintenance or upgrades.
•
Install rack stabilizers (if available) before you mount the chassis.
•
Provide an adequate chassis ground (earth) connection for your router chassis.
In addition to the preceding guidelines, review the precautions for avoiding excessive temperature conditions
in the “Site Environmental Requirements” section in the Preparing Your Site for Installation chapter.
The following table provides the Cisco ASR 1001 Router dimensions and weight information.
Table 87: Cisco ASR 1001 Router Dimensions and Weight
DimensionsCisco ASR 1001
22.50 in. (57.15 cm)Depth
1.71 in. (43.43 mm) - 1RU rack-mountHeight
17.25 in. (43.815 cm) - 19 inch rack-mountWidth
40 lb (18.143 k) - fully configuredWeight
Guidelines for an Equipment Shelf or Tabletop Installation
The chassis should already be in the area where you will install it. If you have not determined where to install
your chassis, see the Cisco ASR 1000 Series Routers Component Overview chapter for information about site
considerations.
Cisco ASR 1000 Series Router Hardware Installation Guide
426
Cisco ASR 1001 Router Overview and Installation
Guidelines for an Equipment Shelf or Tabletop Installation

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
