Four-Post Rack Installation
The Cisco ASR 1004 Router can be flush-mounted in a 19-inch equipment rack using the rack-mounting kit
provided with your system. The Cisco ASR 1004 Router can be mounted into the rack using two recommended
methods:
•
Installing the chassis in an existing rack with equipment.
•
Installing an empty chassis in a rack with no equipment installed.
When handling the chassis, always follow proper lifting practices. See the “Chassis-Lifting Guidelines” section.
Inner clearance (the width between the inner sides of the two posts or rails) must be at least 19 inches
(48.26cm). The height of the chassis is 6.95 inches (17.653 cm). Airflow through the chassis is from front
to back.
Note
Make sure the rack is stabilized.Note
SUMMARY STEPS
1.
(Optional) Install a shelf in the rack to support the Cisco ASR 1004 Router. If you are using a shelf then
raise the chassis to the level of the shelf. Let the bottom of the chassis rest on the brackets, but continue
to support the chassis.Using two people, lift the chassis into the rack using the side handles and grasping
underneath the power supply bays.
2.
Position the chassis until the rack-mounting flanges are flush against the mounting rails on the rack.
3.
Hold the chassis in position against the mounting rails while the second person finger-tightens a screw to
the rack rails on each side of the chassis. The following image shows the rear rack-mount brackets and
the front rack-mount brackets on the Cisco ASR 1004 Router.
4.
Finger-tighten 4 more screws to the rack rails on each side of the chassis.
5.
Tighten all screws on each side to secure the chassis to the equipment rack.
6.
Use a level to verify that the tops of the two brackets are level, or use a measuring tape to verify that both
brackets are the same distance from the top of the rack rails.
DETAILED STEPS
Step 1
(Optional) Install a shelf in the rack to support the Cisco ASR 1004 Router. If you are using a shelf then raise the chassis
to the level of the shelf. Let the bottom of the chassis rest on the brackets, but continue to support the chassis.Using two
people, lift the chassis into the rack using the side handles and grasping underneath the power supply bays.
Step 2
Position the chassis until the rack-mounting flanges are flush against the mounting rails on the rack.
Use the third hole up from the bottom of the rack-mount bracket and the third hole down from the top of the
rack-mount bracket.
Note
Cisco ASR 1000 Series Router Hardware Installation Guide
199
Cisco ASR 1004 Router Overview and Installation
Four-Post Rack Installation

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
