DescriptionDirectionSignalPin
——
NC7,8
Cisco ASR 1006 Router BITS Port Signals and Pinouts
The following table lists the pinouts of the Building Integrated Timing Supply (BITS) RJ45 port on the Cisco
ASR 1006 Router.
Table 98: BITS RJ-45 Receptacle Pinouts for Cisco ASR1000-RP1
DescriptionDirectionSignalPin
Receive RingInputRX Ring1
Receive (T1/E1)InputRX2
——
N/C3, 4
—
UnusedTX Ring5
—
UnusedTX6
——
N/C7,8
The following table lists the pinouts of the Building Integrated Timing Supply (BITS) and the DOCSIS Timing
Interface (DTI) RJ45 port on the Cisco ASR1000-RP2 front panel.
Table 99: BITS RJ-45 Receptacle Pinouts for Cisco ASR1000-RP2
DescriptionDirectionSignalPin
Receive
Ring/Bidirectional DTI
Input/Bi (DTI)RX Ring1
Receive TIP (T1/E1)
Bidirectional DTI
Input/Bi (DTI)RX TIP2
——
N/C3, 4
Transmit
Ring/Bidirectional DTI
OutputTX Ring5
Transmit TIP (T1/E1)
Bidirectional DTI
OutputTX6
——
N/C7,8
Cisco ASR 1000 Series Router Hardware Installation Guide
618
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1006 Router BITS Port Signals and Pinouts

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
