Removing the DC Power Supply from Cisco ASR 1013 Router
Before you can remove a DC power supply from the Cisco ASR 1013 Router, you must remove power from
the power supply. Follow these steps to remove power and the DC power supply from the chassis.
Make certain that the chassis ground is connected before you begin removing and installing the power
supply.
Caution
SUMMARY STEPS
1.
Before servicing the power supply, switch the circuit breaker Off in your equipment area. As an additional
precaution, tape the circuit breaker switch in the Off position.
2.
Slip on the ESD-preventive wrist strap that was included in the accessory kit.
3.
Switch the power supply circuit breaker switch to Off (O).
4.
Locate the terminal block on the rear of the chassis on the power supply.
5.
Remove the slotted plastic cover from the terminal block (see xref fig).
6.
Loosen the four captive screws on the DC power supply.
7.
Grasping the power supply handles, pull the power supply from the chassis.
8.
Replace the DC power supply within five minutes.
DETAILED STEPS
Step 1
Before servicing the power supply, switch the circuit breaker Off in your equipment area. As an additional precaution,
tape the circuit breaker switch in the Off position.
Step 2
Slip on the ESD-preventive wrist strap that was included in the accessory kit.
Step 3
Switch the power supply circuit breaker switch to Off (O).
Step 4
Locate the terminal block on the rear of the chassis on the power supply.
Cisco ASR 1000 Series Router Hardware Installation Guide
592
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing a DC Power Supply in Cisco ASR 1013 Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
