Cisco ASR 1001 Hardware Installation Guide

•
Provide hardware abstraction layer between the packet processing-based forwarding engine and other
system components.
The Cisco ASR1000-ESP5, Cisco ASR1000-ESP10, Cisco ASR1000-ESP10-N, Cisco ASR1000-ESP20,
Cisco ASR1000-ESP40, Cisco ASR1000-ESP100, and Cisco ASR1000-ESP200 provide centralized
forwarding-engine options for the Cisco ASR 1000 Series Aggregation Services Routers. The Cisco ASR
1002-F Router includes a nonmodular, integrated embedded services processor with a forwarding bandwidth
(throughput) of 2.5 Gbps. The integrated embedded services processor of the Cisco ASR 1002-X Router can
provide a forwarding bandwidth of 5 Gbps, 10 Gbps, 20 Gbps, or 36 Gbps.
The Cisco ASR1000-ESP10-N is the nonencryption version of the Cisco ASR1000-ESP10. The Cisco
ASR1000-ESP10-N can only support noncrypto Cisco IOS software images. It does not support encryption
capabilities such as IPsec.
The Cisco ASR 1000 Series Routers support the following Cisco ASR 1000 Series Embedded Services
Processors:
The embedded services processor can be upgraded only on redundant embedded services processor systems
(Cisco ASR 1006 Router and Cisco ASR 1013 Router). The Cisco ASR 1002 router supports only one
Cisco ASR1000-ESP5 or ASR1000-ESP10. The Cisco ASR 1006 Router and Cisco ASR 1004 Router
do not support the Cisco ASR1000-ESP5. When performing upgrades, the Cisco ASR1000-ESP10, Cisco
ASR1000-ESP20, and any future ESPs can be upgraded.
Note
Do not have different embedded services processors operating in the same chassis. The only time this
condition occurs is when you are performing an upgrade.
Note
•
Cisco ASR 1000-ESP5, page 88
•
Cisco ASR 1000-ESP10, page 89
•
Cisco ASR 1000-ESP20, page 89
•
Cisco ASR 1000-ESP40, page 89
•
Cisco ASR 1000-ESP100, page 90
•
Cisco ASR 1000-ESP200, page 91
•
Features of the Cisco ASR 1000 Series Embedded Services Processors, page 94
Cisco ASR 1000-ESP5
The Cisco ASR1000-ESP5 forwarding performance will vary depending on features configured. Up to 4 Mpps
for the combination of the following commonly-used features: IPv4 forwarding, IP Multicast, ACL, QoS,
Reverse Path Forwarding (RPF), load balancing, and Sampled NetFlow.
Cisco ASR 1000 Series Router Hardware Installation Guide
88
Cisco ASR 1000 Series Routers Embedded Services Processors
Cisco ASR 1000-ESP5

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
