Cisco ASR 1001 Hardware Installation Guide

SpecificationDescription
Height: 3.5 in. (8.9 cm)
Width: 17.25 in. (19-inch rack-mount or optional 23 Telco adaptor
brackets)
Depth: 22.50 in. (including card handles, cable-management
brackets, and power supply handles) for mounting in a
600mm-enclosed cabinet
Dimensions (H x W x D)
•
40 lbs (18.143 kg) for a fully loaded Cisco ASR 1002 Router
or Cisco ASR 1002-F Router
•
43.35 lbs (19.662 kg) for a fully loaded Cisco ASR 1002-X
Router
Weight
•
41° to 104° F
•
5° to 40° C
Nominal operating temperature
10% to 85%Nominal operating humidity
• –38° to 150° F
• –40° to 70° C
Storage temperature
•
Maximum DC: 590W
•
Maximum AC: 560W
•
Maximum (Out): 470W
Power consumption
Cisco ASR 1002 Router Mgmt Ethernet RJ-45 Port Pinouts
Unless stated otherwise, the specifications for the Cisco ASR 1002-X Router are the same as the Cisco
ASR 1002 Router specifications listed in this section.
Note
The Cisco ASR 1002 Router has RJ-45 port for the 10/100/1000 Ethernet connections. The RJ-45 port supports
IEEE 802.3ab (Gigabit Ethernet) and IEEE 802.3u (Fast Ethernet) interfaces compliant with 10BASET,
100BASETX, and 1000BASET specifications.
The RJ-45 port supports standard straight-through and crossover Category 5 UTP cables with RJ-45 connectors.
Cisco does not supply Category 5 UTP cables; these cables are available commercially.
The following table lists the RJ-45 port pinout for the front panel Management Ethernet port.
Cisco ASR 1000 Series Router Hardware Installation Guide
626
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1002 Router Mgmt Ethernet RJ-45 Port Pinouts

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
