During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself. Statement 94
Warning
Before you begin, read the following important notices:
•
The Cisco ASR1000-RP1 requires an OIR (shutdown).
•
The reason you would be removing an internal hard drive is that it is failing or failed; so any data recovery
may be lost.
•
If the drive is functioning, you can back it up to a drive plugged into a USB port using the archive tar
command.
•
To restore the backup copy from an external USB flash memory stick plugged into a USB port to the
internal hard drive, type in:
archive tar /xtract usb0:asr1000.tar harddisk
•
Verify that the internal hard drive installation was successful
Removing and Replacing the Cisco ASR1000-RP1 Module Internal Hard Drive
The Cisco ASR 1000 Series route processor (RP1) contains an internal hard drive disk that provides nonvolatile
storage in the form of an internal flash disk. The Cisco ASR 1000 Series RP1 module can be configured with
either a 40 GB or a 32 GB disk. Both components are field-replaceable on the Cisco ASR 1006 Router and
the Cisco ASR 1004 Router (there is no hard disk in the Cisco ASR 1002 Router). On the front panel of the
Cisco ASR 1000 Series RP, the DISK HD LED indicates activity on the hard drive.
This section explains how to remove a hard drive assembly from the Cisco ASR1000-RP1 module and replace
it with a new internal hard drive.
Removing the Cisco ASR1000-RP1 Internal Hard Drive
To remove the Cisco ASR1000-RP1 from the Cisco ASR 1000 Series Router, follow this procedure:
Cisco ASR 1000 Series Router Hardware Installation Guide
477
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the Cisco ASR1000-RP1 Module Internal Hard Drive

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
