Cisco ASR 1001 Hardware Installation Guide

•
ESI state path support for redundant ASR 1000 forward processors
•
Dual ESI support for four carrier cards (in slots 0 though 3) and single ESI support for two carrier cards
(in slots 4 and 5).
•
Total bandwidth or throughput of 40 Gbps
It provides 40 Gbps bandwidth per system and at least 10 Gbps aggregated security traffic.
All initial Cisco ASR 1000 Series Embedded Services Processors are based on a common highly-programmable
network Cisco QuantumFlow Processor (packet processing). The Cisco ASR 1013 Router slots are keyed
using rotated guide pins so that plug-in cards can only be fully inserted in slots where they are intended to
operate. This keying prevents cards from making midplane contact in slots the cards are not allowed.
The Cisco ASR1000-ESP10 and ESP20 will not plug into the Cisco ASR 1013 Router ESP slots.Note
Cisco ASR 1000-ESP100
Cisco ASR1000-ESP100 is a CPP-based embedded services processor for the Cisco ASR1000 Series Routers.
It is a field-replaceable unit (FRU), and it is capable of supporting online insertion and removal (OIR) operations
in conjunction with one or two route processors, a secondary embedded services processor, and up to six SPA
carrier cards.
Cisco ASR 1000-ESP100 is supported on the following routers:
•
Cisco ASR 1006 Router
•
Cisco ASR 1013 Router
Cisco ASR1000-ESP100 provides the following features:
•
24 configurable ESI links for SPA Carrier Card and native Line Card support:
◦
ESI links support with a bandwidth of up to 46 Gbps for the Cisco ASR 1013 Router on Sip slots
0,1,4, and 5.
◦
ESI links support with a bandwidth of up to 110 Gbps for the Cisco ASR 1013 Router on Sip slots
2 and 3.
•
ESI punt path support for dual redundant ASR 1000 route processors with a bandwidth of 11 Gbps
•
ESI state path support for redundant ASR 1000 forward processors
It can support at least 20 Gbps of aggregated security traffic.
All Cisco ASR 1000 Series embedded services processors are based on a common highly-programmable
network Cisco QuantumFlow Processor (packet processing). The Cisco ASR 1013 Router slots are keyed
using rotated guide pins so that plug-in cards can only be fully inserted in slots where they are intended to
operate. This keying prevents cards from making midplane contact in slots the cards are not allowed.
Cisco ASR 1000 Series Router Hardware Installation Guide
90
Cisco ASR 1000 Series Routers Embedded Services Processors
Cisco ASR 1000-ESP100

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
