This completes the procedure for installing the chassis on a two-post rack. Proceed to the Figure 161: Attaching a
Grounding Lug to the Chassis Ground Connector, on page 349 for information about how to continue with the installation.
Four-Post Rack Installation
The Cisco ASR 1002-X Router can be flush-mounted in a 19-inch equipment rack using the rack-mounting
kit provided with your system. The Cisco ASR 1002-X Router can be mounted into the rack using two
recommended methods:
•
Installing the chassis in an existing rack with equipment.
•
Installing an empty chassis in a rack with no equipment installed.
When handling the chassis, always follow proper lifting practices. See the “Chassis-Lifting Guidelines” section
on page 5-23 .
Inner clearance (the width between the inner sides of the two posts or rails) must be at least 19 inches
(48.26 cm). The height of the chassis is 3.47 inches (8.8 cm). Airflow through the chassis is from front to
back.
Note
Ensure that the rack is stabilized.Note
SUMMARY STEPS
1.
(Optional) Install a shelf in the rack to support the Cisco ASR 1002-X Router. If you are using a shelf,
raise the chassis to the level of the shelf. Let the bottom of the chassis rest on the brackets, but continue
to support the chassis. Lift the chassis into the rack using the side handles and grasping underneath the
power supply bays, with the help of another person.
2.
Position the chassis until the rack-mounting flanges are flush against the mounting rails on the rack.
3.
Hold the chassis in position against the mounting rails while the second person finger-tightens a screw to
the rack rails on each side of the chassis.
4.
Tighten all the screws on each side to secure the chassis to the equipment rack (see the following image).
5.
Use a level to verify that the tops of the two brackets are level, or use a measuring tape to verify that both
the brackets are the same distance from the top of the rack rails.
DETAILED STEPS
Step 1
(Optional) Install a shelf in the rack to support the Cisco ASR 1002-X Router. If you are using a shelf, raise the chassis
to the level of the shelf. Let the bottom of the chassis rest on the brackets, but continue to support the chassis. Lift the
chassis into the rack using the side handles and grasping underneath the power supply bays, with the help of another
person.
Step 2
Position the chassis until the rack-mounting flanges are flush against the mounting rails on the rack.
Cisco ASR 1000 Series Router Hardware Installation Guide
343
Cisco ASR 1002-X Router Overview and Installation
Four-Post Rack Installation

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
