Cisco ASR 1001 Hardware Installation Guide

*For information about the
DB-25 alarm connector, how
it works, and Cisco ASR
1000 series route processor
LEDs, see the xref section.
Note: Shielded cables must
be used to connect to the
DB-25 alarm connector on
both the AC and DC power
supplies, in order to comply
with
FCC/EN55022/CISPR22
Class A emissions
requirements.
Step 4
Unplug the power cable from the AC inlet on the back of the power supply and the power source.
Step 5
Unscrew the power supply captive screws.
The Cisco ASR 1013 router has two power zones, each containing two power supplies for a redundant system.
Power supplies must be installed in the chassis at all times to ensure sufficient cooling. The system fans are
inside the power supply units and must spin for cooling. Because all the system fans can be powered by one
power supply, the second power supply unit does not have to be powered on, but it must be installed.
Note
If you remove a power supply, the system can run for a maximum of five minutes before the system shuts
down. The fans and power elements are independent within the power supply. Therefore, it is not required
that the replacement power supply be energized within five minutes. The only requirement is that the power
supply be installed in the chassis, which energizes the fans and maintains proper system cooling.
Caution
Step 6
Grasping the power supply handles, pull the power supply from the chassis.
Step 7
Replace the AC power supply within five minutes.
What to Do Next
This completes the procedure for removing the AC power supply from the Cisco ASR 1013 chassis.
Replacing the AC Power Supply in Cisco ASR 1013 Router
This section provides information about installing an AC power supply in the Cisco ASR 1013 Router.
Never install an AC power module and a DC power module in the same chassis. Statement 1050Danger
Cisco ASR 1000 Series Router Hardware Installation Guide
589
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing an AC Power Supply in Cisco ASR 1013 Router

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
